10KW 48Vdc COMPLETE OFF GRID SOLAR PANEL KIT 120V/240Vac LITHIUM BATTERY 52 X 195W BIFACIAL SOLAR PANELS
10KW 48Vdc COMPLETE OFF GRID SOLAR PANEL KIT 120V/240Vac LITHIUM BATTERY 52 X 195W BIFACIAL SOLAR PANELS
SKU: L02M195TM-NK5KWUSL2240-52
Code:
Copy Code5000W 48V Solar Hybrid Inverter Charger supports up to 6 units (30kw Max.) in parallel. It's capable of single-phase or split-phase parallel. that means, it can output 110V and 220V at the same time.
ECO-WORTHY Bifacial 195 Watt 12V Mono solar panel is fully weather proof and professionally made with high quality components. Increase power generation by an additional 15%.
ECO-WORTHY 12V 280Ah LiFePO4 Lithium Iron Phosphate Battery contains 6000+ deep cycles, each lithium battery can run for more than 15 years, which is 3 times longer cycles than other LiFePO4 batteries on the market.
ECO-WORTHY 10000W 48V MPPT Solar Kit can be used for several different purposes, including homes, etc. Whatever the kit is used for, you can rest assured that you are purchasing a quality system. If you have any questions regarding this product, please contact us info@eco-worthy.com.
Package Includes
28.67kWh Lithium Battery Bank
52x Bifacial 195W Mono Solar Panel
2x 5000W 48V Solar Hybrid Inverter Charger
2x 5M 8AWG Extension Cable with MC4
4x 5M 12AWG Solar Cable with MC4
2x Y MC4 Connector
52x Z Mounting Bracket
8x 280Ah 12V Stackable LiFePO4 Lithium Battery
5x 2AWG Battery Interconnect Cable
43kWh Lithium Battery Bank
52x Bifacial 195W Mono Solar Panel
1x 5000W 48V Solar Hybrid Inverter Charger
2x 5M 8AWG Extension Cable with MC4
4x 5M 12AWG Solar Cable with MC4
2x Y MC4 Connector
52x Z Mounting Bracket
12x 280Ah 12V Stackable LiFePO4 Lithium Battery
8x 2AWG Battery Interconnect Cable
Bifacial 195W Monocrystalline Solar Panel
Rated Power: 195W | Solar Cell: Monocrystalline |
Maximum/Peak Voltage(Vmp): 19.8V | Open Circuit Voltage(Voc): 23.7V |
Short circuit current: 10.5A | Maximum current: 9.85A |
Output Tolerance: ±3% | Temperate coefficient of Isc: (010+/-0.01)%/℃ |
Temperate coefficient of Voc: -(0.38+/-0.01)%/℃ | Temperature range: -40℃~ +85℃ |
Frame: Aluminum alloy frame | Weight: 20.48 lbs(9.29 kg) |
Size: 52.6x26.38x1.38in (1335*670*35mm) |
5000W 48V Solar Hybrid Inverter Charger
AC Input Mode | |
Rated Input Voltage: 110/120VAC | Input Voltage Range: 90V-140VAC |
Frequency: 50Hz/60Hz(auto detect) | Overload/Short Circuit Protection: Circuit breaker |
Efficiency: >95% | AC Reverse Protection: Available |
Max Bypass Overload Current: 40A | |
Invert Mode | |
Output Voltage Waveform: Pure Sine Wave | Rated Output Power: 5000W |
Rated Output Voltage: 120VAC | Peak Power: 10000W |
Bypass Breaker: 63A | Rated Battery Input Voltage: 48V |
Min Starting Voltage: 44V | Power Saving Mode: Load ≤25W |
AC Charging Mode | |
Battery Type: Lead acid or lithium battery | Max Charge Current: 60A |
Charge Voltage Range: 40-60VDC | Overcharge Protection: Alarm and turn off charging after 1 minute |
PV Charging Mode | |
Max Input Power: 5000W | PV Charging Current Range:0-80A(can be set) |
Max PV Open Circuit Voltage: 500VDC | PV Operating Voltage Range: 60-145VDC |
MPPT Voltage Range: 120-450VDC | Battery Voltage Range: 40-60VDC |
Max Output Power: 5000W | Charging Short Circuit Protection: Blown fuse |
280Ah LiFePO4 Lithium Battery
Battery Capacity: 280Ah | Battery Power: 3584Wh |
Battery Voltage: 12.8V | Maximum Charging Current: 250A |
Maximum Discharging Current: 250A | Max Charge Voltage: 14.5V |
Discharge Cut-Off Voltage: 10V | Operating Temperature: -4°F to 140°F |
Cycle Life: ≥6000 at 50% DoD (depth of discharge) | Size: 20.98*9.48*8.81inch |
Weight: 63.93lbs |
16.4 feet 12AWG Cables
Cable Type: Connecting Solar Panels to Charge Controller | Rating Voltage: 600/1000V |
Length: 5 meters(16 ft) | Conductor: Tinned copper wire |
AWG: 11 | Normal Cross Sectional Area of the Conductor (mm2): 4 |
Waterproof: IP 65 Protection | Temperature: -40°F to +185°F |
Connector: MC4 | Weight: 0.742KG |
Z Mounting Brackets
4 pieces of Z shape solar panel brackets | 8 pieces of stainless steel nuts and cap bolts |
Y Branch Cable MC4 Connectors
Compatible with MC4 solar connector. | Easy installation for 2 solar panels connected in parallel. |
